- Size: 16
- Place of Origin: China
- Brand Name: BSY
- Model Number: BQ1226/8E1
- Weight: 15000.000 kg
Max.cutting diameter(mm) | 170-800 |
Max,cutting length(mm) | 2150-2700 |
Range of veneer thickness(mm) | 0.35-3.9 |
Chuck diameter(mm) | 100 |
Max.rotating speed of spindel(rpm) | 0-160 |
Quick forward and backward speed of tool cartridge(m/min) | 1.8 |
Relief angle motor power | 0.75 |
Main motor power(kw) | 75 |
Rapid feed motor power(kw) | 4 |
Hydraulic motor power(kw) | 7.5 |
Grinding angle of appropriate tool cartridge | 18o-22o |
General motor(kw) | 89.5 |
Overall dimensions(mm) | 8250×2855×1554 |
Weight(kg) | 16500 |
- Size: 16
- Place of Origin: China
- Brand Name: BSY
- Model Number: BQ1226/8E1
- Weight: 15000.000 kg
